Cylindrical Ceiling LED Light PMMA 512mm

Scratchproof 512mm PMMA Cylindrical Ceiling Light.
Order code: TLED12-24  24V, TLED12-230  230V.

Product with limited availability. Delivery may be delayed.

Configure your lamp and buy RIMSA excellence
SKU: TLED12 Categories: ,

Description

Functions and certifications

rimsa - ce mark icon - industrial lamps

CE

rimsa - golia icon - industrial lamps

Golia

rimsa - ECO icon - industrial lamps

ECO

rimsa - ik 07 icon - industrial lamps

IK 07

rimsa - ip 68 icon - industrial lamps

IP 68

rimsa - led icon - industrial lamps

Led

Technical specifications

TLED12-24

Power consumption
12 W
Power supply
24 V ca/cc
Size
512xØ70 mm
Protection
PMMA
IP grade
IP 67
IK grade
IK 07
Color temperature
6.500 K
LED Lifespan
50.000 hours

TLED12-230

Power consumption
12 W
Power supply
230 V ca/cc
Size
512xØ70 mm
Protection
PMMA
IP grade
IP 67
IK grade
IK 07
Color temperature
6.500 K
LED Lifespan
50.000 hours

LED lamp and illumination

Features

The PMMA 512 mm cylindrical Led PMMA ceiling light is available in both 24V and 230V. The difference between the two versions is the class: the 24V falls under Class III, while the 230V falls under Class II. Both versions can be fixed with two locking brackets. The 70mm-diameter scratch-resistant PMMA (polymethylmethacrylate) cylindrical body encloses an LED lamp with two end caps at the end. By tightening the three screws located on the side caps, an OR gasket compresses, adhering perfectly to the inner wall of the cylinder. This closure ensures an IP67-type watertight seal.

Tips for use

Sealed ceiling lights are particularly suitable for illuminating the machine tool workspace, where well-layered linear illumination of both the spindle and the work area is needed. The machine tool operator always has excellent illumination even in the presence of water jets and coolant emulsions.

The product has limited availability.
