Rectangular Ceiling Light PSLED23W-230

The PS23W Led model is part of the rectangular ceiling light series. The only available color of the lamp is black, as the aluminum is anodized and not painted. It is powered by a cable-free electronic power supply, which includes active power factor compensation, fast-start control, and protection against removal of the LED tube during its operation. The two LED tubes (t5) and the power supply are placed directly inside the ceiling light. On the side cap, the connection terminal to the external cable is provided, so to operate the lamp it is not necessary to disassemble the whole ceiling light. The PS23W Led is fixed by means of 4 clips, which will have to be inserted into the lower guides of the body. The side parts made of molded polymer material are screwed directly to the extruded aluminum body, while the front part of the ceiling light is covered by the 4mm tempered pyrex glass screen and perfectly sealed with a polyurethane gasket.
The luminous flux is reflected by a specially designed diffuser screen. All materials are resistant to common solvents, degreasing agents and lubricating and cooling emulsions. IP67 degree of protection.
The terminal for connection to the external cable with maximum measurements of M20x1.5 mm is provided on the side cap. To access the electrical connection terminal, the cable press sealed with an o-ring seal must first be removed. As a result, to follow the electrical connection to the machine it is not necessary to disassemble the ceiling light, which reduces the possibility of error and shortens installation time.

High quality and good cooling of the electronic ballast and tubes are prerequisites for an operating life of 50,000 hours. The electronic ballast includes active power factor compensation, rapid turn-on control, and protection against removal of the LED tube during operation. The light fixture is attached to the machine by means of technopolymer retainers inserted into the lower rails on the side of the aluminum body. 4 retainers are included in the standard delivery. All lighting fixtures are supplied with LED tubes. Maximum operating temperature of 50°C.

Its use is recommended for workbenches, production lines, cnc machines and in the mechanical industry.

The product has limited availability.

See the data sheet for more information on the model.

The PS Led is available at 23W or 18W.
